Rotary Type Automatic PU Single Density Injection Moulding Machine NSK-717

Rotary Type Automatic PU Single Density Injection Moulding Machine NSK-717

Location:Taichung City, Taiwan

orCall 886-4-2533-1108

Description

LCD touchable setting with a display on the computer screen make it easy to operate and monitor the state of machine. High effective electronic controlling. We can adjust and set different PU injection volume for each station to meet different requests of mold. Special design for mixing head, grinding-proof, precise mixing materials. After injecting can clear residue automatically without any solvent. PU material tank with stable thermos and stirring, also with double-layer thermos-cycle barrel to ensure the normal property of material.

Specifications

ConditionNew
No. of station20 Station
Size of mold availableL:380 × W:180 mm
Height of last383 mm
Electric motor7.5HP × 1(Disc Pump)6HP × 1(Shaft) HP
Electric heating capacity21 kw
Total electric consumption35 kw
Oil tank volume390 L
Machine sizeL:8100 × W:4280 × H:2360 mm
Machine weight17 tons
