NSK-826
NSK-826
Location:Taichung City, Taiwan
orCall 886-4-2533-1108
Description
LCD touchable setting, easy to operate. Display on computer screen, easy to monitor the state of machine.
High effective electronic controlling, can adjust and set different PU injection volume for each station to meet different requests of mold.
Special design for mixing head, grinding-proof, precise mixing materials. After injecting can clear residue automatically without any solvent.
A hidden motor drives axis part directly, low noise and high effects, during running in high speed can rotary smoothly and can be controlled precisely. Also with axis-protecting system to ensure the axis with high effective running.
Auto machine clip the mixing screw rod, fixed steadily and exchange knife quickly.
PU material tank with stable thermos and stirring, also with double-layer thermos-cycle barrel to ensure the normal property of material.
Specifications
Condition | New |
Mold clamp frame | 24 station |
Motor of hydraulic pump (disc) | 7.5HPx1, 3HPx1 Kw |
Size of side mold | 400x200 (420x200) mm |
Last height | 333, 383, 433, 483, 533 mm |
Screw rod diameter | φ25 mm |
Pump delivery rate | 20 cm³/rev |
Tank capacity (material polyol+iso) | 250×4 L |
Capacity of thermal coal oil | 130 L |
Power consumption (full load) for wiring | 59 Kw |
Machine dimension | 11000×9900×2260 mm |
Machine weight | 28 ton |
